GACIA SL RGB 3COL piloto de señalización LED 24V AC/DC rojo verde azul 22mm empotrable

The GACIA SL RGB 3COL is a high-quality LED indicator light designed for industrial control panels and automation systems. With three selectable colors (red, green, blue) and a 22mm mounting diameter, it provides clear visual status indication in a compact, durable package.

Advantages

Long lifespan of over 30,000 hours reduces maintenance costs. IP65 front panel protection ensures reliable operation in dusty or wet environments. Screw terminals simplify wiring, and the clear lens offers a neutral appearance when off.

Suitable for

• Industrial control panels
• Automation systems
• Machine status indication
• Process monitoring

Key specifications

• Product Type: LED Indicator Light
• Light Source: LED
• Number of Colors: 3 (Red, Green, Blue)
• Color Modes: Red, Green, Blue (selectable)
• Series: GACIA SL
• Mounting Diameter: 22 mm
• Operating Voltage: 24V AC/DC
• Current Consumption: <20 mA
• Terminal Type: Screw Terminals
• Front Panel Protection Rating: IP65
• Operating Temperature Range: -25°C to +70°C
• Lifespan: >30,000 hours
• Bezel Material: Plastic
• Lens Color (Off State): Clear
• Lens Shape: Flat
• Mounting Type: Panel Mount
• Certifications: CE, RoHS

Recommendations

For optimal performance, ensure the mounting hole is 22mm and the supply voltage is 24V AC/DC. Use with appropriate panel cutout and secure screw terminals.
