GIRA 384200 Mecanismo de pulsador de desconexión, bipolar, NO, 250 V AC, 10 A, empotrar

This Gira insert is a two-pole momentary OFF switch without fixing claws, built for flush mounting in standard Gira frames. It delivers a clean, deliberate OFF signal in control circuits, making it a dependable choice for lighting or automation setups where a maintained ON state is not wanted.

Highlights

• 2-pole momentary OFF switching (Normally Open contact)
• Flush-mounted insert with screw fixing, no claws
• Rated 250 V AC / 10 A, screw terminals
• Halogen-free thermoplastic body
• Fits Gira System 55, E2, Event, Esprit, Standard 55, Flächenschalter

In daily use

Install it behind any compatible Gira cover plate. The momentary action sends a brief OFF pulse, ideal for staircase timers, impulse relays, or scene control. Screw terminals accept solid or stranded conductors up to 2.5 mm², and the compact insert leaves room for deep back boxes.

Full specifications

• Product type: Momentary switch insert
• Switching function: OFF (Taster Aus)
• Poles: 2
• Contact configuration: Normally Open (NO)
• Mounting: Flush-mounted, screw fixing without claws
• Rated voltage: 250 V AC
• Rated current: 10 A
• Connection: Screw terminals
• Material: Halogen-free thermoplastic
• Compatible design lines: Gira System 55, E2, Event, Esprit, Standard 55, Flächenschalter
• Operating temperature: -20 °C to +40 °C
• Certification: VDE

Final note

For a reliable OFF command in any Gira installation, this insert pairs simplicity with proven switching performance.
