Goobay BH AA 10xL portapilas pasivo para 10 pilas AA, conexión en serie, salida 15V, negro 11986

When you're prototyping a portable device or building a custom battery pack, the Goobay BH AA 10xL passive battery holder gives you a reliable foundation for powering your project. This holder accommodates ten AA (Mignon) batteries in a series arrangement, delivering a nominal 15 V DC with alkaline cells or 12 V DC with rechargeable NiMH/NiCd batteries. The open-top design allows quick battery swaps, while tinned wire ends make soldering or connecting to your circuit straightforward.

Key specifications

• Compatible battery type: AA (Mignon)
• Number of batteries: 10
• Battery arrangement: series
• Nominal output voltage: 15 V DC (alkaline), 12 V DC (NiMH/NiCd)
• Connection: 2 tinned wire ends (red/black), cable length 150 mm
• Material: ABS plastic, black
• Operating temperature: -10 °C to +60 °C
• Storage temperature: -20 °C to +70 °C
• Polarity marking: clearly indicated (+/-)
• Mounting: passive, free-standing or integrated

Why choose it

This holder is built from durable ABS plastic and features metal spring contacts for secure battery retention. The clear polarity markings and colour-coded wires reduce the risk of connection errors, saving you time during assembly. Its passive design means no additional electronics are needed—just insert batteries and connect your load.

Ideal use cases

• DIY electronics and prototyping
• Portable power supplies for sensors, motors, or LED projects
• Educational kits and hobbyist builds
• Replacement battery compartment for custom devices

Good to know

The holder is designed for easy integration into enclosures or standalone use. Keep in mind that the output voltage depends on the battery chemistry: alkaline cells provide 1.5 V each, while rechargeable NiMH/NiCd cells provide 1.2 V each. Always observe polarity when connecting your circuit.
