GoodConnections Alcasa GC-N0130 módulo keystone RJ45 apantallado Cat6a - 10GbE, 22-26 AWG, negro

In high-speed network installations, a weak link in the connection chain can throttle performance and introduce interference. The GoodConnections Alcasa GC-N0130 Cat6a shielded keystone module eliminates that bottleneck, delivering reliable 10 Gigabit Ethernet connectivity in a compact, easy-to-install form factor. Whether you're wiring a data center, office building, or smart home, this module ensures every link operates at peak efficiency.

Who is it for

This module is ideal for network installers, IT professionals, and DIY enthusiasts building or upgrading structured cabling systems. It suits applications requiring high bandwidth and noise immunity, such as server rooms, PoE-powered devices, and multimedia streaming.

Main features

• Supports 10 Gigabit Ethernet (10GbE) over Cat6a cabling, with backward compatibility to Cat6 and Cat5e.
• Fully shielded design (STP/FTP) with a steel housing to protect against EMI and crosstalk.
• Tool-free termination with IDC contacts for solid or stranded wires from 22 to 26 AWG.
• Gold-plated contacts (50µm) ensure low resistance and long-term corrosion resistance.
• PoE, PoE+, and 4PPoE (UPoE) compatible for powering devices like access points and IP cameras.
• Standard keystone footprint fits patch panels, wall plates, and surface mount boxes.
• Supports TIA/EIA 568-A/B wiring schemes for flexible installation.

Specifications

• Product type: Keystone module
• Connector type: RJ45 female
• Data transfer rate: 10 Gigabit Ethernet
• Cable category: Cat6a (backward compatible with Cat6, Cat5e)
• Shielding: Shielded (STP/FTP)
• Termination: IDC (insulation-displacement connector)
• Supported wire gauge: 22-26 AWG (solid and stranded)
• Wiring standard: TIA/EIA 568-A/B
• Housing material: Steel
• Colour: Black
• Contact plating: Gold (50µm)
• PoE support: PoE, PoE+, 4PPoE/UPoE
• Mounting standard: Keystone
• Operating temperature: -10°C to 60°C
• Certifications: RoHS, CE

Tips

For optimal performance, pair this module with Cat6a shielded cable and shielded connectors. Use a proper punch-down tool for secure terminations. When installing in high-density panels, allow adequate space for cable management to maintain bend radius and reduce stress on connections.
