GRAFENTHAL Cable de conexión Cat6 S/FTP CU 0,5m gris

The GRAFENTHAL Patch Cable Cat6 S/FTP CU is a high-performance network cable designed for reliable data transmission in professional environments. With a length of 0.5 meters, it is ideal for short connections between network devices, patch panels, and workstations. The cable features S/FTP shielding (screened and foiled twisted pairs) to minimize electromagnetic interference, ensuring stable and fast data transfer.

Advantages

This patch cable offers excellent signal integrity and protection against crosstalk and external noise. The 100% copper stranded conductors provide flexibility and durability, while the gold-plated RJ45 connectors (50µm) ensure corrosion-resistant, reliable connections. The snagless molded boot design protects the locking tab from damage during installation and removal.

Suitable for

• Connecting PCs, routers, switches, and patch panels in data centers and offices
• 10 Gigabit Ethernet (10GBASE-T) networks requiring high bandwidth
• Structured cabling systems where space is limited

Key specifications

• Cable Type: Patch Cable
• Cable Category: Cat6
• Shielding: S/FTP (Screened/Foiled Twisted Pair)
• Conductor Material: 100% Copper (CU)
• Conductor Type: Stranded
• Cable Length: 0.5 m
• Color: Grey
• Connector Type: RJ45 Male to RJ45 Male
• Connector Plating: Gold-plated contacts (50µm)
• Wiring Standard: TIA/EIA 568B
• Data Transfer Rate: Up to 10 Gigabit Ethernet (10GBASE-T)
• Bandwidth: Up to 250 MHz
• AWG: 27 AWG
• Jacket Material: PVC
• Boot Type: Molded, Snagless
• Outer Diameter: Approx. 6.0 mm
• Operating Temperature: -20°C to 60°C
• Compliance: RoHS, CE

Recommendations

For optimal performance, use this cable with Cat6-compatible devices and ensure proper cable management to avoid kinking or sharp bends. Ideal for short-distance patching in high-density environments.
