GRAFENTHAL Cable de conexión Cat6 S/FTP CU 0,5m gris

The GRAFENTHAL Patch Cable Cat6 S/FTP CU is a high-performance Ethernet cable designed for reliable, high-speed network connections. With a length of 0.5 meters, it is ideal for short-distance patching in server rooms, data centers, or home networks. The cable features S/FTP shielding (pairs in metal foil plus overall braid) to minimize electromagnetic interference, ensuring stable data transmission. Made with stranded copper conductors and gold-plated RJ45 connectors, it supports up to 10 Gigabit Ethernet over short distances and is backward compatible with Cat5e and Cat5 networks.

Advantages

This patch cable offers superior shielding against EMI/RFI, reducing crosstalk and signal degradation. The LSZH (Low Smoke Zero Halogen) jacket enhances safety by emitting minimal smoke and no toxic halogen gases in case of fire. Its 27 AWG stranded conductors provide flexibility for easy routing in tight spaces. Gold-plated contacts ensure corrosion resistance and reliable connectivity over time.

Suitable for

• Connecting computers, switches, routers, and patch panels in local area networks (LANs)
• Data centers and server rooms requiring high-speed, interference-free connections
• Home networks for streaming, gaming, or file transfers
• Industrial environments where LSZH safety is required

Key specifications

• Cable Type: Ethernet Patch Cable
• Category: Cat6
• Shielding: S/FTP (PiMF)
• Conductor Material: Copper (CU)
• Conductor Type: Stranded
• Length: 0.5 m
• Color: Grey
• Connector Type: RJ45 Male to RJ45 Male
• Connector Plating: Gold-plated (50µm)
• Jacket Material: LSZH
• Bandwidth: Up to 250 MHz
• Data Transfer Rate: Up to 10 Gbps (10GBASE-T)
• Wiring Standard: TIA/EIA 568B
• Conductor Gauge: 27 AWG
• Compliance: RoHS, CE

Recommendations

For optimal performance, use this cable with Cat6-compatible network equipment. Ensure connectors are fully inserted to maintain shielding integrity. Ideal for short patch connections where flexibility and high data rates are required.
