GRAFENTHAL Cable de conexión CAT6A S/FTP CU 0,5m gris

The GRAFENTHAL Patch Cable CAT6A S/FTP CU is a high-performance Ethernet cable designed for demanding network environments. With a length of 0.5 meters and a sleek grey jacket, this cable ensures reliable, high-speed data transmission for your critical connections.

Advantages

This patch cable offers exceptional shielding with S/FTP construction, protecting against electromagnetic interference and ensuring signal integrity. The 100% copper conductors and gold-plated RJ45 connectors provide optimal conductivity and durability. Its snagless, molded boot design prevents damage during installation and removal, while the LSZH jacket enhances safety in enclosed spaces.

Suitable for

• Data centers and server rooms requiring high-density cabling
• 10 Gigabit Ethernet networks (10GBASE-T)
• PoE applications including PoE, PoE+, and 4PPoE/PoE++
• Industrial and commercial environments where halogen-free materials are required

Key specifications

• Cable Type: Patch Cable
• Category: CAT6A
• Shielding: S/FTP
• Conductor Material: 100% Copper (CU)
• Length: 0.5 m
• Color: Grey
• Connector Type: RJ45 Male to RJ45 Male
• Connector Plating: Gold-plated (50µ)
• Wiring Standard: TIA/EIA 568B
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Bandwidth: Up to 500 MHz
• Data Transfer Rate: Up to 10 Gbps
• Conductor Gauge: AWG 27/7 (Stranded)
• Outer Diameter: Approx. 6.2 mm
• Boot Type: Snagless, Molded
• PoE Support: Yes (PoE, PoE+, 4PPoE/PoE++)
• Halogen Free: Yes
• Certifications: RoHS, CE

Recommendations

For optimal performance, pair this cable with CAT6A compatible switches and patch panels. Ensure proper cable management to maintain airflow and reduce strain on connectors.
