GRENTON DIGITAL IN MINI Flush TF-Bus v3 Módulo

The GRENTON DIGITAL IN MINI Flush TF-Bus v3 Module (model INP-310-T-01) connects two potential-free contact devices and two 1-Wire temperature sensors to a smart home system. It is designed for flush mounting in a wall box.

Key features

• Connects 2 potential-free contact devices (e.g., light switches, motion sensors, smoke sensors, flood sensors)
• Supports 2 1-Wire temperature sensors
• Flush mounting in a wall box

Specifications

• Bus power supply: 24 V DC
• Maximum power consumption: 0.1 W
• Maximum current consumption (@24V): 4 mA
• Weight: 12 g
• Dimensions (H/W/D): 32/32/9 mm
• Operating temperature range: 0 – 45 °C
• Number of supported 1-Wire temperature sensors: 2
