Cámara de videoconferencia MAXHUB UC S15 12 MP 4K Ultra HD 30 fps

The MAXHUB UC S15 is an all-in-one video collaboration bar designed for huddle rooms and small meeting spaces. It features a built-in system with a 12 MP sensor and 4K Ultra HD 30 fps capture, a 120° field of view, and both wired and wireless BYOD support for flexible connection and content sharing.

Advantages

The device offers plug-and-play wireless sharing via the MAXHUB Wireless dongle or the MAXHUB Share app, and wired BYOD via the included USB-C cable to access the camera, microphones, and speaker. Compact and simple to install, it provides automatic framing and speaker tracking to keep the active participants centered. Intelligent focus delivers individual close-ups for multiple participants simultaneously. Six beam‑forming microphones with AI noise reduction and a studio‑quality Hi‑Fi speaker (8 W + 3 W with dedicated tweeter and woofer) ensure clear two‑way audio across huddle and small rooms. Remote management is supported through MAXHUB Pivot for centralized monitoring and updates.

Suitable for

• Huddle rooms and small meeting spaces
• Hybrid meetings and remote collaboration
• Quick BYOD presentations (wired or wireless)
• Rooms requiring compact, easy installation

Key specifications

• Image sensor: 12 MP
• Video resolution: up to 4K Ultra HD at 30 fps
• Field of view: 120°
• Optical/digital zoom: up to 5x digital zoom
• Microphones: 6 beam‑forming microphones with AI noise reduction
• Speaker output: 8 W + 3 W with dedicated tweeter and woofer
• Connection methods: USB-C (wired), Wi‑Fi (wireless), wireless dongle or sharing app for BYOD
• Mounting: stand or wall mount compatible
• Color: Black

How to use

For wireless BYOD, plug the MAXHUB Wireless dongle (WT13M) into your laptop or use the MAXHUB Share app to connect and share content while accessing the UC S15 camera, microphones, and speaker. For wired BYOD, connect your laptop to the UC S15 using the supplied USB‑C cable to display content and use the device’s audio and video. Place or mount the UC S15 so the 120° field of view covers the meeting area; the system will apply auto framing, speaker tracking, and intelligent focus automatically during calls.

Recommendations

Position the device centrally on or above the display at head height where possible, keep the meeting area free of large obstructions for optimal 120° coverage, and use the wired USB‑C connection for the most stable content sharing when network conditions are limited. Use MAXHUB Pivot for central device monitoring and firmware updates.
