Guangzhou Shirui TCP35T Consola táctil extendida para XCore Kit Pro - infrarrojos

The Guangzhou Shirui TCP35T Extended Touch Console is a dedicated control interface designed for the XCore Kit Pro control systems. Featuring a 3.5-inch TFT LCD display with infrared touch technology, this console provides intuitive and reliable control over your AV and automation environments. Its compact design fits standard single-gang wall boxes, making it ideal for permanent installations, or it can be used on a desktop with an optional stand.

Advantages

This touch console offers real-time system control with customizable graphical user interfaces, allowing you to tailor the experience to your specific needs. The integrated IR blaster enables direct control of IR-enabled devices, while the RS-232 port provides bidirectional serial communication for advanced integration. Power over Ethernet (PoE) simplifies installation by eliminating the need for a separate power supply, though a DC 12V option is also available.

Suitable for

• Control rooms and command centers
• Conference rooms and meeting spaces
• Home automation and smart building systems
• Educational and training facilities
• Any environment requiring centralized control of AV equipment

Key specifications

• Display: 3.5-inch TFT LCD, 320x240 pixels (QVGA), 4:3 aspect ratio
• Touch Technology: Infrared (IR) Touch
• Connectivity: 1x Ethernet (RJ45), 1x RS-232 (bidirectional), 1x IR Output
• Power: PoE IEEE 802.3af Class 0 or DC 12V
• Processor: High-performance Embedded ARM Processor
• Operating System: Embedded Linux-based OS
• Mounting: Standard single-gang wall box or desktop (optional stand)
• Housing: High-quality ABS plastic, black color
• Operating Temperature: 0°C to 45°C (32°F to 113°F)
• Storage Temperature: -20°C to 60°C (-4°F to 140°F)
• Humidity: 10% to 90% RH (non-condensing)

Recommendations

For optimal performance, pair the TCP35T with the Shirui XCore Kit Pro control system. Use shielded CAT5e or CAT6 cables for Ethernet connections to ensure reliable PoE and data transmission. The console is designed for indoor use only; avoid exposure to extreme temperatures or moisture.
