GVS Touchpanel S3 10,1 pulgadas Panel táctil KNX con portero automático y servidor de aplicaciones, negro 503051163

Managing building automation, video intercom, and remote access from separate devices creates unnecessary complexity. The GVS Touchpanel S3 consolidates these functions into a single wall-mounted interface, simplifying control for residential and commercial installations.

Who is it for

This panel is intended for KNX installers, system integrators, and building owners who need a unified control point for lighting, climate, shading, and communication. It suits projects where a premium glass-front design and integrated intercom are required.

Main features

• 10.1-inch IPS capacitive multi-touch display with 1280 x 800 resolution for sharp visuals.
• Built-in SIP-based video intercom with 2MP camera, microphone, and speaker.
• Integrated app server enables remote control via the GVS Home App.
• Runs Android 9.0 on a quad-core ARM Cortex-A17 processor with 2GB RAM and 8GB storage.
• Connectivity via Ethernet (RJ45) and dual-band Wi-Fi (2.4GHz/5GHz).
• Additional sensors for temperature, proximity, and ambient light enable automation.
• Flush-mounted design with aluminum frame and black glass front.

Specifications

• Display: 10.1" IPS, 1280 x 800, capacitive multi-touch
• Operating system: Android 9.0
• Processor: Quad-core ARM Cortex-A17
• Memory: 2GB DDR3 RAM, 8GB eMMC storage
• Intercom: SIP video, 2MP camera, built-in speaker and microphone
• Network: Ethernet RJ45, Wi-Fi 2.4/5GHz
• Power: 24V DC, max 10W (external adapter required)
• Mounting: Flush-mounted (box not included)
• Colour: Black

Tips

Verify that your KNX bus and network infrastructure are ready before installation. A separate flush-mounted box and 24V DC power supply are required. For remote access, configure the app server and network settings during commissioning.
