Hager B800803 canaleta de cables PVC negra 80x80 mm 2 m

Routing and protecting cables in electrical installations can be a challenge, especially when you need a solution that is both robust and easy to install. The Hager B800803 cable trunking offers a practical way to organize and conceal wiring, keeping it safe from damage and your space looking tidy.

Who is it for

This trunking is ideal for electricians, contractors, and DIY enthusiasts working on surface-mounted electrical installations in residential, commercial, or industrial settings. It is suitable for anyone who needs a reliable cable management system that can be installed quickly and provides long-term protection for cables.

Main features

• Made from PVC (Polyvinyl Chloride) for durability and resistance to impact.
• Black colour (RAL 9005) for a neutral, professional appearance that blends with many environments.
• External dimensions: 80 mm width x 80 mm height, providing ample space for multiple cables.
• Length: 2000 mm (2 meters), allowing for extended runs with fewer joints.
• Snap-on lid for easy access to cables during installation and maintenance.
• Single compartment design simplifies cable organization.
• Surface mount type, suitable for walls and other flat surfaces.
• Self-extinguishing PVC material enhances fire safety.
• Temperature resistance from -5°C to +60°C, suitable for various indoor conditions.

Specifications

• Material: PVC
• Colour: Black
• External width: 80 mm
• External height: 80 mm
• Length: 2000 mm
• Mounting type: Surface mount
• Lid type: Snap-on
• Number of compartments: 1
• Halogen-free: No
• Self-extinguishing: Yes
• Temperature resistance: -5°C to +60°C
• Impact resistance: IK07
• Protection class: IP40 (with lid)
• Compliance standard: EN 50085-2-1

Tips

When installing, ensure the surface is clean and dry for optimal adhesion if using adhesive, or use appropriate screws for a secure mechanical fixing. Cut the trunking to length using a fine-toothed saw and deburr the edges to avoid damaging cable insulation. For a neat finish, use matching end caps and fittings from the same range.
