Hager K67H canal de suelo 110mm gris claro 2m

In commercial offices and industrial facilities, the Hager K67H floor cable duct keeps power and data cables protected and neatly organized. This 2-metre duct features two chambers and a light grey PVC construction, suitable for walkable areas and light vehicle traffic.

Key specifications

• Length: 2000 mm
• Width: 110 mm
• Height: 20 mm
• Material: PVC
• Colour: Light grey (RAL 7035)
• Number of chambers: 2
• Protection class: IP40
• Impact resistance: IK07
• Operating temperature: -5 °C to +60 °C
• Halogen-free: No
• Lead-free: Yes
• Mounting type: Floor, screwable
• Application area: Indoor, commercial, industrial, residential
• Load bearing capacity: Walkable, suitable for light vehicle traffic
• Fire behaviour: Self-extinguishing
• Standards compliance: EN 50085-2-2

Why choose it

The K67H provides a robust solution for routing cables across floors without compromising safety or aesthetics. Its self-extinguishing PVC material and IK07 impact resistance ensure durability in high-traffic environments.

Ideal use cases

• Office spaces with open floor plans
• Retail environments needing temporary power distribution
• Industrial workshops with light vehicle movement
• Residential areas where floor-level cable management is required

Good to know

The duct is screwable for secure installation and complies with EN 50085-2-2 for cable trunking systems. It is not halogen-free, so consider ventilation requirements in enclosed spaces.
