Hager LE1835 contactor modular 25A 230V AC 2NO+2NC 4 polos

The Hager LE1835 is a high-quality modular contactor designed for reliable switching and control of electrical loads in residential and commercial installations. With a rated current of 25 A and a coil voltage of 230 V AC, this 4-pole contactor features 2 normally open (NO) and 2 normally closed (NC) contacts, making it versatile for various applications. It is built to meet EN 61095 standards and offers excellent electrical and mechanical endurance.

Advantages

Compact design with 3 module width for space-saving DIN rail mounting. High durability with 100,000 electrical and 1,000,000 mechanical cycles. Low power consumption of 1.5 VA holding and 4.5 VA pull-in. Suitable for a wide operating temperature range from -10 to +50 °C.

Suitable for

• Switching of lighting, heating, and motor loads
• Control panels and distribution boards
• Industrial and commercial automation systems

Key specifications

• Rated Current (In): 25 A
• Coil Voltage (Uc): 230 V AC
• Contact Configuration: 2 NO + 2 NC
• Number of Poles: 4
• Rated Insulation Voltage (Ui): 500 V
• Rated Impulse Withstand Voltage (Uimp): 4 kV
• Frequency: 50/60 Hz
• Mounting: DIN Rail
• Protection Degree: IP20 (terminals), IP40 (front)
• Connection Capacity: Rigid 1.5-16 mm², Flexible 1.5-10 mm²

Recommendations

For optimal performance, ensure proper mounting on a DIN rail and use appropriate cable cross-sections. This contactor is ideal for applications requiring reliable switching under moderate electrical loads.
