HAGER WNA003 conmutador de control con tecla W.1, unipolar, 10 AX, 250 V AC, blanco polar

Control changeover switch with rocker for flush-mounted installation, featuring a built-in neon control light to indicate switching status at a glance. Its 1-pole changeover contact supports lighting circuits with a rated current of 10 AX at 250 V AC.

Advantages

Halogen-free thermoplastic housing in polar white (RAL 9010) blends discreetly into modern interiors. Screw terminals accept rigid conductors from 1.5 to 2.5 mm², ensuring a secure and durable connection. The W.1 design line offers a consistent look across Hager switch ranges.

Suitable for

• Switching lighting circuits in residential and commercial buildings
• Standard flush-mounted boxes with an installation depth of approximately 32 mm
• Changeover (two-way) switching applications where a control indicator is required

Key specifications

• Switch type: control changeover switch
• Number of poles: 1
• Operation: rocker
• Rated current: 10 AX
• Rated voltage: 250 V AC
• Connection: screw terminals, 1.5–2.5 mm² rigid
• Illumination: neon control light
• Colour: polar white (RAL 9010)
• Material: halogen-free thermoplastic
• Protection class: IP20
• Design line: Hager W.1

Recommendations

For a clean and functional two-way lighting control with clear status indication, pair this switch with a compatible Hager W.1 rocker cover plate.
