HAGER WNA040 Conmutador doble con tecla 2 módulos W.1 blanco polar

Electricians and installers choose the HAGER WNA040 for flush-mounted installations in residential and commercial buildings where reliable switching of lighting circuits is required. This double two-way switch from the W.1 series offers two independent rockers in a single compact unit, making it ideal for controlling lights from two locations such as staircases, corridors, or large rooms.

Key specifications

• Switch type: Double two-way switch (Doppel-Wechselschalter)
• Number of gangs: 2
• Series: Hager W.1
• Mounting type: Flush-mounted
• Operation type: Rocker
• Rated voltage: 250 V AC
• Rated current: 10 AX
• Connection type: Screw terminals
• Terminal capacity: 1.5 – 2.5 mm² (rigid conductors)
• Material: Thermoplastic
• Halogen-free: Yes
• Colour: Polar white
• IP protection class: IP20
• Compatibility: Standard flush-mount boxes
• Backlight/indicator: No

Why choose it

The WNA040 combines durable thermoplastic construction with a clean polar white finish that blends into any interior. Its screw terminals accept rigid conductors from 1.5 to 2.5 mm², ensuring secure connections. The halogen-free material supports modern building requirements, and the IP20 rating suits indoor use.

Ideal use cases

• Staircase lighting with two-way switching.
• Corridor or hallway light control from two points.
• Residential and commercial flush-mounted installations.

Good to know

The switch fits standard flush-mount boxes and does not include a backlight, but it can be retrofitted with a separate lamp if indicator functionality is needed.
