HEINRICH KOPP comprobador de tensión unipolar 324206030

Single-pole voltage tester for quick phase detection and voltage presence checks in AC circuits from 125 to 250 V. The integrated neon lamp indicates live conductors without the need for batteries.

Advantages

Passive operation requires no power source, ensuring the tester is always ready for use. The slim metal probe tip allows access to tight terminal spaces, while the plastic housing provides insulation and a secure grip.

Suitable for

• Electricians and maintenance personnel
• DIY enthusiasts performing basic electrical checks
• Verifying phase presence in sockets and switches

Key specifications

• Test type: single-pole
• Voltage range AC: 125 – 250 V
• Frequency range: 50 – 500 Hz
• Indication: neon lamp
• Housing material: plastic
• Probe tip material: metal
• Operating temperature: -10 °C to +50 °C
• Overvoltage category: CAT II 250 V

Recommendations

Use this tester for quick, battery-free phase detection in standard household and commercial electrical installations.
