Heinrich Kopp entrada de cable C2f BlueElectric antracita

Cable routing through enclosure walls often leaves gaps that invite dust, moisture, and mechanical strain. The Heinrich Kopp Cable Entry C2f from the BlueElectric series closes that vulnerability with a precision-engineered gland for corrugated pipes, ensuring a clean, protected transition every time.

Who is it for

Electricians, panel builders, and maintenance teams working on industrial control cabinets, junction boxes, or outdoor enclosures will appreciate this component's dependable sealing and straightforward installation. It suits environments where IP65 protection is non-negotiable and where cables must be routed neatly through corrugated conduit.

Main features

• Secure fit for corrugated pipes with nominal size NW17 (DN17)
• Metric M20 x 1.5 thread for fast, tool-friendly mounting
• Durable polyamide (PA6) body, halogen-free and UV-resistant
• IP65 protection against dust and water jets
• Wide operating range from -25 °C to +60 °C
• Glow wire tested at 750 °C for enhanced fire safety
• Anthracite finish blends into modern enclosures

Specifications

• Brand: Heinrich Kopp
• Model: C2f
• MPN: 321615004
• EAN: 4008224654487
• Product type: Cable entry
• Series: BlueElectric
• Colour: Anthracite
• Material: Polyamide (PA6)
• Thread type: Metric
• Thread size: M20 x 1.5
• Compatible pipe size: NW17 (DN17)
• Protection class: IP65
• Operating temperature: -25 °C to +60 °C
• Halogen-free: Yes
• UV resistance: Yes
• Glow wire test: 750 °C
• Mounting method: Screw thread
• Wrench size: 27 mm
• Thread length: 10 mm

Tips

For a lasting seal, push the corrugated pipe fully into the entry until it bottoms out, then tighten the gland with a 27 mm wrench. Avoid over-torquing to prevent thread damage. This cable entry is ideal for both indoor and sheltered outdoor applications thanks to its UV-stable, halogen-free construction.
