HellermannTyton 300-32543 base de fijación adhesiva para bridas, 28x28 mm, negra, PA66

Keeping cables organized on smooth surfaces can be a challenge, especially when drilling holes is not an option. The HellermannTyton 300-32543 solves this with a self-adhesive mounting base that provides a secure anchor point for cable ties without damaging the surface.

Who is it for

This mounting base is ideal for electricians, network installers, and maintenance technicians who need a quick, non-invasive way to route cables along panels, walls, or equipment enclosures. It works best on clean, flat, non-porous surfaces such as metal, glass, or painted wood.

Main features

• Adhesive backing with synthetic rubber for strong initial bond
• Made of durable polyamide 6.6 (PA66) in black
• Compact square design: 28 mm long, 28 mm wide, 6.3 mm high
• Accepts cable ties up to 4.8 mm wide
• Halogen-free and RoHS compliant

Specifications

• Material: Polyamide 6.6 (PA66)
• Colour: Black
• Length: 28 mm
• Width: 28 mm
• Height: 6.3 mm
• Max. cable tie width: 4.8 mm
• Operating temperature (material): -40 °C to +85 °C
• Adhesive temperature range: -20 °C to +65 °C
• Flammability rating: UL94 V2
• Application environment: Indoor

Tips

For best adhesion, clean the surface with isopropyl alcohol and let it dry before applying the base. Press firmly for a few seconds and allow the adhesive to cure for 24 hours before loading with cables.
