HellermannTyton 402-06180 Tubo termorretráctil, 2:1, 12,7mm, negro, 1,2m, poliolefina

This heat shrink tubing from HellermannTyton offers a reliable 2:1 shrink ratio, making it suitable for insulating and protecting cables and connectors. The black polyolefin material provides good resistance to chemicals and UV, and the tubing is self-extinguishing per UL224 VW-1.

Highlights

• Supplied internal diameter: 12.7 mm, recovers to 6.4 mm for a snug fit
• Length: 1.2 m, enough for multiple applications
• Operating temperature range: -55 °C to +135 °C, with minimum shrink temperature of +90 °C
• Dielectric strength: 20 kV/mm, tensile strength: 15 MPa
• Meets UL224 VW-1 and CSA C22.2 No. 198.1 standards

In daily use

Simply slide the tubing over the area to be protected and apply heat. It shrinks to 50% of its original diameter, creating a tight, insulating seal. The recovered wall thickness of 0.64 mm provides durable protection against abrasion and environmental factors.

Full specifications

• Material: Polyolefin
• Colour: Black
• Shrink ratio: 2:1
• Supplied internal diameter: 12.7 mm
• Recovered internal diameter: 6.4 mm
• Recovered wall thickness: 0.64 mm
• Length: 1.2 m
• Operating temperature range: -55 °C to +135 °C
• Minimum shrink temperature: +90 °C
• Dielectric strength: 20 kV/mm
• Tensile strength: 15 MPa
• Flame retardancy: Self-extinguishing (UL224 VW-1)
• UV resistance: Good
• Chemical resistance: Good
• Standards met: UL224 VW-1, CSA C22.2 No. 198.1
• Packaging quantity: 1 piece

Final note

With its wide temperature range and flame-retardant properties, this tubing is a solid choice for electrical insulation and mechanical protection in demanding environments.
