HellermannTyton 561-03101 soporte para bridas autoadhesivo amarillo, 28x28mm, pack de 500

In control cabinets and on smooth equipment panels, technicians need a fast, reliable way to anchor cable ties without drilling. The HellermannTyton 561-03101 Q-Mount cable tie mount provides a self-adhesive base in yellow, sized for cable ties up to 4.8 mm wide. Each pack contains 500 mounts, making it practical for large installations or ongoing maintenance work.

Key specifications

• Type: Cable tie mount
• Mounting: Self-adhesive (acrylate)
• Material: Polyamide 6.6 (PA66)
• Colour: Yellow
• Dimensions: 28.0 mm length × 28.0 mm width × 6.7 mm height
• Max. cable tie width: 4.8 mm
• Operating temperature: -40 °C to +85 °C
• Flammability rating: UL94 V2
• Quantity per pack: 500

Why choose it

The PA66 body withstands everyday mechanical stress, while the acrylate adhesive bonds to clean, smooth surfaces. The low 6.7 mm profile keeps cable runs close to the panel, and the yellow colour is easy to spot during inspection.

Ideal use cases

• Securing wire bundles inside electrical enclosures
• Routing cables along machine frames without drilling
• Organising network or control wiring in retrofit projects

Good to know

The mount is part of the Q-Mount series and is halogen-free. For best adhesion, surfaces should be clean, dry, and free of grease before application.
