HellermannTyton Base autoadhesiva para bridas 19x19 mm natural PA66 (308-32403)

This self-adhesive mounting base offers a quick, screw-free way to secure cable ties on smooth surfaces. Its compact 19 x 19 mm footprint and natural PA66 body make it suitable for light-duty cable routing in enclosures, control panels, and on equipment housings.

Highlights

• Self-adhesive backing with synthetic rubber adhesive for fast installation
• Accepts cable ties up to 4.8 mm wide
• Made from halogen-free polyamide 6.6 (PA66), UL94 V2
• Operating temperature range: -40 °C to +85 °C (product)
• Supplied in packs of 100 pieces

In daily use

Clean the mounting surface, peel off the protective liner, and press the base firmly in place. For best adhesion, install at temperatures between +10 °C and +30 °C. The adhesive reaches full bond strength after a short curing time. Once fixed, thread a cable tie through the base and around your cable bundle.

Full specifications

• Product type: Cable tie mounting base
• Mounting method: Self-adhesive
• Material: Polyamide 6.6 (PA66)
• Colour: Natural
• Base length: 19 mm
• Base width: 19 mm
• Height: 4.5 mm
• Maximum cable tie width: 4.8 mm
• Operating temperature range (product): -40 °C to +85 °C
• Flammability rating: UL94 V2
• Adhesive material: Synthetic rubber
• Operating temperature range (adhesive): -10 °C to +60 °C
• Halogen-free: Yes
• UV resistance: No
• RoHS compliance: Yes
• Packaging unit: 100 pieces
• Recommended installation temperature: +10 °C to +30 °C
• Application surface: Smooth, clean, grease-free surfaces

Final note

For reliable bonding, ensure the surface is free of dust, oil, and moisture before application.
