Hikvision DS-KAS342 Kit de control de acceso de una puerta con reconocimiento facial, 720p

The Hikvision DS-KAS342 is a comprehensive single-door access control kit featuring advanced face recognition technology. Designed for secure and convenient entry management, this kit includes a face recognition terminal, electric strike lock, exit button, and power supply, providing everything needed for a complete access control solution.

Advantages

This kit offers contactless face recognition with a fast recognition speed of less than 0.2 seconds per user, supporting up to 1,500 faces and 3,000 cards. The 4.3-inch LCD touch screen and dual-lens camera ensure clear 720p video and reliable operation even in harsh environments, with an IP65-rated terminal and wide temperature range.

Suitable for

• Small to medium businesses requiring secure single-door access
• Office buildings, warehouses, and retail stores
• Integration with existing security systems via TCP/IP, Wi-Fi, RS-485, and Wiegand

Key specifications

• Kit Components: DS-K1T342MFWX Face Recognition Terminal, DS-K4T100-U1 Electric Strike Lock, DS-K7P01 Exit Button, DS-K4P01 Power Supply
• Access Control Type: Face Recognition, Card (Mifare 1), PIN
• Door Capacity: Single Door
• Face Capacity: 1,500 faces
• Card Capacity: 3,000 cards
• Event Capacity: 150,000 events
• Terminal Display: 4.3-inch LCD Touch Screen
• Terminal Camera: 2 MP Dual-Lens (Wide-Angle, IR Fill Light)
• Video Resolution: 720p
• Face Recognition Distance: 0.3 to 1.5 m
• Face Recognition Speed: < 0.2 s per user
• Communication Interfaces: TCP/IP, Wi-Fi, RS-485, Wiegand
• Input/Output Interfaces: Lock Output, Exit Button, Door Contact, Tamper, Alarm I/O
• Power Supply (Kit): 12 VDC, 3 A
• Terminal Power Supply: 12 VDC, 2 A
• Operating System: Linux
• Ingress Protection (Terminal): IP65
• Lock Type: Electric Strike Lock (Fail-Secure)
• Operating Temperature (Terminal): -30°C to 60°C (-22°F to 140°F)

Recommendations

For optimal performance, ensure proper installation and network connectivity. The kit is ideal for upgrading existing door access systems with modern face recognition capabilities.
