HP DesignJet T1600dr PostScript impresora de gran formato de 36"

Architecture firms and engineering teams rely on the HP DesignJet T1600dr to produce precise technical drawings, maps, and renderings up to 36 inches wide. With dual front-loading rolls and a 500 GB self-encrypting hard disk, it handles high-volume printing while keeping sensitive project data secure. The 15.6-inch touchscreen simplifies job management, and the integrated cutter delivers ready-to-use prints without manual trimming.

Key specifications

• Print width: 36 inches (914 mm)
• Print technology: HP Thermal Inkjet
• Ink system: 6-ink (Cyan, Magenta, Yellow, Photo Black, Matte Black, Gray)
• Maximum resolution: 2400 x 1200 optimized dpi
• Print speed: 26 seconds per A1/D print (180 A1/D prints per hour)
• Media handling: Dual automatic front-loading roll feeds, sheet feed, automatic cutter
• Hard disk: 500 GB self-encrypting
• Memory: 128 GB (virtual)
• Connectivity: Gigabit Ethernet (1000Base-T)
• Printer languages: Adobe PostScript 3, Adobe PDF 1.7, HP-GL/2, HP-RTL, TIFF, JPEG, CALS G4, URF
• Display: 15.6-inch touchscreen
• Security: HP Secure Boot, Whitelisting, Secure File Erase, IPsec, 802.1x
• Power consumption (printing): 100 W
• Minimum line width: 0.02 mm (HP-GL/2 addressable)
• Maximum roll diameter: 170 mm
• Maximum media thickness: 0.8 mm

Why choose it

Dual rolls let you switch between paper types without reloading, cutting downtime on mixed-media jobs. The PostScript/PDF engine ensures accurate rendering of complex vector files, while the self-encrypting hard disk protects confidential plans. HP Secure Boot and whitelisting guard against firmware tampering, making it suitable for government and defense contractors.

Ideal use cases

• Architectural and engineering drawings (CAD, BIM)
• GIS maps and large-format posters
• High-volume technical document production
• Secure printing of confidential project files

Good to know

The printer supports media up to 0.8 mm thick and rolls up to 170 mm in diameter, accommodating a wide range of substrates. It includes a 15.6-inch touchscreen for intuitive operation and comes with a one-year warranty. For network integration, Gigabit Ethernet provides fast data transfer, and the printer supports HP Click software for easy job submission from PCs or Macs.
