HP PBA-DADFCLX-6240FX alimentador automático de documentos dúplex (DADF) para CLX-6240FX

The HP PBA-DADFCLX-6240FX is a genuine OEM Duplex Automatic Document Feeder (DADF) designed for HP/Samsung CLX-6240FX and compatible multifunction printers. This top-mounted module enables automatic two-sided scanning, copying, and faxing of multi-page documents, boosting office productivity.

Advantages

Single-pass duplex scanning saves time by processing both sides of a document in one pass. With a 50-sheet capacity, it handles large jobs without constant reloading. The Contact Image Sensor (CIS) technology ensures reliable, high-quality scans.

Suitable for

• HP/Samsung CLX-6200FX, CLX-6220FX, CLX-6240FX, CLX-6250FX, CLP-670ND, CLX-6260FW, CLX-6260ND, CLX-6260FD, CLX-6260FR
• Office environments requiring efficient duplex scanning and copying

Key specifications

• Product Type: Duplex Automatic Document Feeder (DADF)
• Document Capacity: 50 sheets
• Duplex Scanning: Yes (Single-pass)
• Media Sizes Supported: A4, A5, A6, Letter, Legal, Folio, Oficio, JIS B5, ISO B5, Executive, Statement, Custom (142 x 148 mm to 216 x 356 mm)
• Media Weight Supported: 60 to 163 gsm
• Scan Technology: Contact Image Sensor (CIS)
• Installation Type: Top-mounted module
• Color: White / Grey
• Scan Speed (Max Duplex): Up to 24 ipm
• Power Source: Powered by host MFP
• OEM: Samsung (now HP)
• Service Part Number: JC91-00970B

Recommendations

This DADF is an original HP part, ensuring perfect fit and reliable performance. Ideal for upgrading or replacing the feeder on compatible Samsung/HP CLX series printers.
