HPE P04560-H21 480GB SATA III 2,5" Read Intensive SSD

Enterprise servers often struggle with storage bottlenecks under heavy read workloads. The HPE P04560-H21 480GB SATA III 2.5" Read Intensive SSD addresses this by delivering fast, reliable performance for read-centric applications in HPE ProLiant, Synergy, and Apollo systems.

Who is it for

IT administrators and data center managers who need a dependable, hot-swappable SSD for read-intensive workloads such as web serving, data streaming, and virtualized environments. It is ideal for enterprises seeking to upgrade server storage with a high-endurance, cost-effective solution.

Main features

• 480 GB capacity with SATA 6Gb/s interface for broad compatibility.
• 2.5-inch small form factor with Smart Carrier for easy hot-swap deployment.
• Read Intensive endurance (1 DWPD) optimized for read-heavy applications.
• Sequential read speeds up to 530 MB/s and write speeds up to 470 MB/s.
• High reliability with 2,000,000 hours MTBF.
• Low power consumption: 2.5 W typical read, 4.5 W typical write.

Specifications

• Drive Type: Solid State Drive (SSD)
• Capacity: 480 GB
• Form Factor: 2.5 inches
• Interface: SATA 6Gb/s
• Endurance Type: Read Intensive (RI)
• NAND Flash Type: TLC (Triple-Level Cell)
• Sequential Read Speed: Up to 530 MB/s
• Sequential Write Speed: Up to 470 MB/s
• Random Read IOPS (4KB): Up to 70,000 IOPS
• Random Write IOPS (4KB): Up to 15,000 IOPS
• DWPD: 1
• Hot-Swap Support: Yes
• Carrier Type: Smart Carrier (SC)
• MTBF: 2,000,000 hours
• Operating Temperature: 0°C to 70°C
• Power Consumption (Active Read): 2.5 W
• Power Consumption (Active Write): 4.5 W

Tips

For optimal performance, pair this SSD with HPE servers that support SATA hot-swap drives. Ensure your server firmware is up to date to enable full functionality and monitoring features.
