Hub USB-C DELOCK 64323 — host USB 3.2 Gen 2 Type-C, HDMI + 2× USB-A + 2× USB-C, 10 Gbit/s, gris

DELOCK 64323 is a compact USB-C hub with a USB 3.2 Gen 2 Type-C host port that expands a single USB-C connection into multiple high-speed interfaces. The hub provides an HDMI output supporting up to 4K at 60 Hz and a mix of USB-A and USB-C downstream ports for data transfer at up to 10 Gbit/s. The aluminium-coloured grey housing measures 42 × 114 × 15 mm, making the unit portable and suitable for mobile work with laptops, tablets or smartphones that support USB-C. The hub supports USB Power Delivery (USB PD 3.0) up to 90 W so a connected laptop or tablet can be charged through the PD-capable Type-C port; the hub also operates without an external power supply when the host provides sufficient power.

Advantages

The hub combines multiple interfaces — HDMI, USB-A and USB-C — in a single, compact device to reduce cable clutter and extend laptop connectivity. With USB 3.2 Gen 2 performance, connected peripherals benefit from up to 10 000 Mbit/s transfer rates for fast file exchange and responsive external drives. The HDMI output supports 4K at 60 Hz for a single external display, and the integrated USB Power Delivery port provides up to 90 W charging capacity for compatible hosts. The robust, small metal housing is designed for portability and everyday use.

Suitable for

• Connecting external monitors for presentations or a single 4K 60 Hz display
• Attaching high-speed external storage, flash drives or card readers
• Expanding USB ports for mice, keyboards and other peripherals while travelling
• Charging a USB-C laptop or tablet via USB Power Delivery up to 90 W

Key specifications

• Host interface: USB 3.2 Gen 2 Type-C (10 Gbit/s)
• Downstream interfaces: HDMI output, USB 3.2 Gen 2 Type-A and Type-C ports
• Maximum data transfer rate: 10 000 Mbit/s
• Display support: HDMI up to 4K (3840 × 2160) at 60 Hz
• Power delivery: USB PD 3.0 support up to 90 W
• Physical size: approximately 42 × 114 × 15 mm; colour: grey
• Number of ports: 7 (combination of USB-A, USB-C and HDMI)

How to use

Connect the hub to a host device with a USB-C port that supports USB 3.2 Gen 2. Attach an external monitor to the HDMI output and plug USB peripherals into the available USB-A or USB-C downstream ports. If charging of the host is required, connect a USB PD-capable power adapter to the hub’s PD Type-C port; the hub will pass power to the host up to the supported 90 W. No additional drivers are required for most modern operating systems; ensure your host operating system supports video output over USB-C and the listed kernel or OS versions for full compatibility.

Recommendations

For reliable video output at 4K 60 Hz and maximum data throughput, use high-quality HDMI cables and USB-C/PD adapters rated for the required bandwidth and power. Verify that your laptop or tablet’s USB-C port supports DisplayPort alt mode or HDMI output and that the operating system version is compatible with USB 3.2 Gen 2 and USB Power Delivery features.
