iBox IUCHCHDVGA Hub USB-C 4 en 1 USB 3.0 + PD 100W + HDMI 4K 30Hz + VGA FullHD

The iBox IUCHCHDVGA is a compact 4-in-1 USB-C multiport hub that extends a single USB-C port into four connections: a USB 3.0 Type-A data port, a USB-C Power Delivery pass-through at up to 100W, an HDMI output at up to 4K 30Hz, and a VGA output for FullHD displays. It is designed for laptops and tablets with a single USB-C port that need to simultaneously drive a monitor, use legacy VGA displays, charge via PD, and connect USB peripherals.

Advantages

The combination of HDMI 4K and VGA outputs in one compact hub makes it versatile for both modern and legacy display setups. The 100W USB-C Power Delivery pass-through allows the host laptop to charge at full speed while all ports remain active, so no separate charging socket is needed. The USB 3.0 port delivers up to 5 Gbit/s data transfer rates for fast external storage or peripherals. The hub is bus-powered from the host USB-C port, requiring no additional power adapter for data use.

Suitable for

• Connecting a 4K HDMI monitor or a FullHD VGA projector from a USB-C laptop
• Keeping a USB peripheral (mouse, keyboard, storage) connected while charging the host via PD 100W
• Business presentations needing both modern HDMI and legacy VGA connectivity

Key specifications

• Brand: iBox
• Model / MPN: IUCHCHDVGA
• EAN: 5903968681463
• Host connection: USB-C male
• Ports: 1x USB 3.0 (USB-A), 1x USB-C PD pass-through (up to 100W), 1x HDMI (up to 4K 30Hz), 1x VGA (up to 1920x1080 FullHD)
• USB data standard: USB 3.2 Gen 1 / USB 3.0 (5 Gbit/s)
• HDMI resolution: up to 3840 x 2160 @ 30 Hz (4K Ultra HD)
• VGA resolution: up to 1920 x 1080 (FullHD)
• Power Delivery: USB PD 3.0 pass-through up to 100W
• Power source: USB bus-powered
• Colour: Silver / Black

How to use

Connect the hub to the USB-C port of your laptop or tablet. Plug in your HDMI or VGA display cable, connect USB peripherals to the USB-A port, and attach a USB-C PD charger to the USB-C PD port to charge your host device simultaneously. No driver installation is required on Windows, macOS, or Linux — the hub is plug and play. Note that simultaneous HDMI and VGA output capability depends on the host device's GPU and driver support.

Recommendations

For reliable 4K HDMI output, ensure the host USB-C port supports DisplayPort Alternate Mode (DP Alt Mode) or Thunderbolt 3. When using PD 100W pass-through, use a certified USB-C PD charger rated at 100W to maximise charging speed to the host device. For VGA output, a standard VGA cable is sufficient for FullHD projection.
