Indicador de señal de entrada con dos sensores ORNO OR-MA-718

The ORNO OR-MA-718 Input Signal Indicator is a professional DIN rail mounted device designed for monitoring two independent 230V AC inputs. It provides clear visual and relay output signaling for voltage presence detection, making it ideal for industrial control panels and building automation systems.

Advantages

Compact 1-module design saves space on the DIN rail. Dual red LED indicators offer immediate visual status of each input. Two independent NO/NC relay outputs allow integration with alarm systems, PLCs, or remote monitoring. Screw terminals ensure secure and reliable wiring.

Suitable for

• Industrial control cabinets
• Building automation and HVAC systems
• Power distribution monitoring
• Alarm and signaling applications

Key specifications

• Input Voltage Monitoring: 2 independent 230V AC inputs
• Number of Sensors: 2
• Indicator Type: 2x Red LED
• Output Type: 2x NO/NC Relay
• Max. Relay Load (Resistive): 16A / 230V AC
• Mounting Type: DIN Rail
• Number of Modules: 1
• Power Supply: 230V AC, 50Hz
• Power Consumption: < 1W
• Operating Temperature: -20°C to +50°C
• Protection Rating: IP20
• Housing Material: Plastic
• Connection Type: Screw Terminals
• Function: Voltage presence detection and signaling

Recommendations

For reliable voltage monitoring and signaling in industrial environments, the ORNO OR-MA-718 offers a compact and robust solution. Ensure proper installation by a qualified electrician.
