Intel Xeon Gold 6554S procesador de 36 núcleos y 72 hilos a 2,2 GHz, 180 MB, FCLGA4677, Tray

The Intel Xeon Gold 6554S is a 36-core, 72-thread processor with a base frequency of 2.2 GHz and a boost frequency of 4 GHz. It features 180 MB cache, a thermal design power of 270 W, and supports DDR5-SDRAM memory up to 4 TB.

Key features

• 36 cores, 72 threads
• Base frequency: 2.2 GHz, boost frequency: 4 GHz
• 180 MB cache
• Intel Xeon Gold processor family
• LGA 4677 (Socket E) socket
• Intel UPI speed: 20 GT/s
• 64-bit operating modes
• 12 high priority cores at 2.4 GHz, 24 low priority cores at 2.0 GHz
• Thermal Design Power (TDP): 270 W
• Processor codename: Emerald Rapids
• ARK processor identification: 237263
• Memory types supported: DDR5-SDRAM
• Memory clock rates supported: 5200 MHz
• Memory channels: Octa-channel
• ECC support
• Max internal memory supported: 4 TB
• No integrated or discrete graphics
• Execute Disable Bit
• Market segment: Server
• Usage conditions: Server/Enterprise
• Max PCI Express lanes: 80
• PCI Express version: 5.0
• Supported instruction sets: AMX, AVX, AVX 2.0, AVX-512, SSE4.2
• Scalability: 2S
• Intel Hyper-Threading Technology
• Intel Turbo Boost Technology 2.0
• Intel AES New Instructions (AES-NI)
• Intel Trusted Execution Technology
• Intel Speed Shift Technology
• Intel Transactional Synchronization Extensions
• Intel Total Memory Encryption
• Intel Control-flow Enforcement Technology (CET)
• Intel Crypto Acceleration
• Intel Platform Firmware Resilience support
• Intel SGX max enclave size: 128 GB
• Intel Trust Domain Extensions (TDX)
• Intel VT-x with Extended Page Tables (EPT)
• Intel OS Guard
• Intel Software Guard Extensions (SGX)
• Intel 64
• Intel Virtualization Technology (VT-X)
• Intel Virtualization Technology for Directed I/O (VT-d)
• AVX-512 FMA units: 2
• Intel Boot Guard
• Intel Deep Learning Boost (DL Boost) on CPU
• Intel Resource Director Technology (RDT)
• Intel Volume Management Device (VMD)
• Intel Run Sure Technology
• Mode-based Execute Control (MBE)
• Intel Speed Select Technology - Base Frequency (SST-BF)
• Intel Total Memory Encryption - Multi Key
• Intel QuickAssist Software Acceleration
• Intel On Demand feature activation
• Intel QuickAssist Technology (QAT): 4 default devices
• Intel Dynamic Load Balancer (DLB): 4 default devices
• Intel Data Streaming Accelerator (DSA): 4 default devices
• Intel Advanced Matrix Extensions (AMX)
• Intel Speed Select Technology - Core Power
• Intel Speed Select Technology - Turbo Frequency
• Tcase: 74 °C
• DTS Max: 91 °C
• Launch date: Q4'23
• Status: Launched
• Number of UPI links: 4
• Package carrier: E1A
• Maintenance status: Baseline Servicing
• Processor package size: 77.5 x 56.5 mm
• Packaging type: Tray

Specifications

• Brand: Intel
• MPN: PK8072205511100
• Processor family: Intel Xeon Gold
• Processor generation: Intel Xeon Scalable 5th Gen
• Processor model: 6554S
• Socket: LGA 4677 (Socket E)
• Cores: 36
• Threads: 72
• Base frequency: 2.2 GHz
• Boost frequency: 4 GHz
• Cache: 180 MB
• TDP: 270 W
• Memory support: DDR5-SDRAM up to 4 TB
• Memory channels: Octa-channel
• Memory clock rates: 5200 MHz
• PCI Express lanes: 80
• PCI Express version: 5.0
• Scalability: 2S
• Package size: 77.5 x 56.5 mm
• Packaging: Tray
