Interruptor automático Eaton PXL-C2/1, 2 A, unipolar, curva C, 6 kA 236047

Electricians and panel builders install the Eaton PXL-C2/1 miniature circuit breaker in distribution boards to protect 230/400 V AC circuits against overload and short-circuit. Its C tripping characteristic suits general lighting and socket circuits with moderate inrush currents.

Key specifications

• Rated current: 2 A
• Tripping characteristic: C
• Number of poles: 1
• Rated voltage: 230/400 V AC
• Rated breaking capacity (Icn): 6 kA
• Frequency: 50/60 Hz
• Mounting: DIN rail
• Terminal type: screw terminals
• Module width: 1 TE (18 mm)
• Energy limiting class: 3
• Degree of protection: IP20 (terminals), IP40 (front)
• Operating temperature: -25 to +75 °C

Why choose it

The PXL-C2/1 combines reliable protection with a compact 1-module width, saving space in crowded distribution boards. Screw terminals provide secure, maintenance-free connections.

Ideal use cases

• Protection of control circuits and small loads in industrial control panels
• Residential and commercial distribution boards for lighting and socket circuits
• Supplemental protection for sensitive equipment with low current draw

Good to know

The breaker complies with EN 60898-1 and IEC 60898-1, ensuring compatibility with standard DIN rail installations.
