JOINT RSS-60-500 PG Conector termorretráctil 4 conductores 6-25 mm² 0,6/1 kV 10 uds.

The JOINT RSS-60-500 PG is a high-quality heat-shrinkable cable joint designed for low voltage power cables. This straight-through joint is suitable for 4-core cables with conductor cross-sections from 6 to 25 mm², rated at 0.6/1 kV. It provides a watertight, UV-resistant, and mechanically robust connection for indoor and outdoor use. The kit includes all necessary components for a reliable installation.

Advantages

This cable joint offers excellent environmental protection, chemical resistance, and mechanical stress resistance. The heat-shrink technology ensures a tight, durable seal that prevents moisture ingress. It is compatible with PVC, XLPE, and EPR insulated cables, making it versatile for various applications. The kit comes with heat-shrink tubes, sealing mastic, cleaning wipe, abrasive cloth, and instructions for easy installation.

Suitable for

• Low voltage power cable connections in electrical networks
• Indoor and outdoor installations
• Industrial, commercial, and residential applications
• Straight-through splicing of 4-core cables

Key specifications

• Product Type: Heat-Shrinkable Cable Joint
• Joint Type: Straight-Through
• Application: Low Voltage (LV) Cables
• Voltage Rating: 0.6/1 kV
• Number of Cores: 4-Core
• Conductor Cross-Section Range: 4 x 6-25 mm²
• Cable Insulation Type Compatibility: PVC, XLPE, EPR
• Sealing Method: Heat-Shrink
• Environmental Protection: Watertight, UV Resistant
• Insulation Material: Polyolefin
• Operating Temperature Range: -20°C to +90°C
• Standards Compliance: CENELEC HD 623 S1, EN 50393
• Connector Compatibility: Crimp or Mechanical Connectors (not included)
• Installation Environment: Indoor and Outdoor
• Resistance: Chemical and mechanical stress resistant
• Kit Contents: Heat-shrink tubes, sealing mastic, cleaning wipe, abrasive cloth, instructions
• Quantity per Pack: 10 pieces

Recommendations

For optimal performance, ensure proper cable preparation and follow the installation instructions. Use compatible crimp or mechanical connectors (sold separately). This joint is ideal for professional electricians and installers working on LV cable networks.
