JONSBO V12 caja de PC Mini-ITX, aluminio, negro

The JONSBO V12 is a premium Mini-ITX PC case crafted with an aluminum alloy exterior and steel interior, offering a compact yet robust chassis for high-performance builds. Its vented aluminum side panel ensures efficient airflow while maintaining a sleek, minimalist aesthetic. Designed for enthusiasts who value space efficiency without compromising on hardware compatibility, the V12 supports SFX/SFX-L power supplies, graphics cards up to 270mm, and CPU coolers up to 135mm.

Advantages

Compact footprint with excellent thermal management: supports up to 2x 120mm or 1x 140mm fans on top and bottom, plus a 92mm rear fan. Radiator compatibility up to 140mm on top and bottom allows for liquid cooling options. The aluminum construction provides durability and a premium feel, while dust filters on the bottom keep the interior clean.

Suitable for

• Mini-ITX gaming or workstation builds
• Users seeking a small form factor case with high-end component support
• Enthusiasts who prefer aluminum aesthetics and vented panels

Key specifications

• Motherboard Support: Mini-ITX
• Material: Aluminum Alloy (Exterior), Steel (Interior)
• Expansion Slots: 2
• Drive Bays: 1x 3.5", 1x 2.5"
• Front I/O: 1x USB 3.0, 1x USB 2.0, HD Audio
• Max GPU Length: 270 mm
• Max CPU Cooler Height: 135 mm
• PSU Compatibility: SFX / SFX-L
• Fan Support: Top 2x 120mm or 1x 140mm, Bottom 2x 120mm or 1x 140mm, Rear 1x 92mm
• Radiator Support: Top up to 140mm, Bottom up to 140mm
• Side Panel: Vented Aluminum
• Color: Black
• Dust Filters: Yes (Bottom)

Recommendations

For optimal airflow, install two 120mm fans on the top and bottom. Pair with an SFX power supply and a compact GPU to maximize interior space. The V12 is ideal for a clean, high-performance Mini-ITX build.
