JUNG fuente de alimentación empotrable para Smart Control NT 2405 VDC

Smart home devices often need a reliable, hidden power source that fits inside a standard wall box. The JUNG NT 2405 VDC solves this by providing a compact, flush-mounted power supply for JUNG Smart Control systems, delivering both 24 V DC for the control unit and 5 V DC for USB-powered accessories.

Who is it for

Electricians and smart home installers who need a discreet, built-in power solution for JUNG Smart Control components in residential or commercial projects.

Main features

• Dual output: 24 V DC (0.5 A) for Smart Control and 5 V DC (1.2 A) for USB devices
• Flush-mounted design fits into standard wall boxes
• Short-circuit proof, overload and overtemperature protection
• Wide input voltage range: 230 V AC, 50/60 Hz
• Operating temperature from -5 °C to +45 °C

Specifications

• Input voltage: 230 V AC
• Input frequency: 50/60 Hz
• Output 1: 24 V DC, 0.5 A, 12 W
• Output 2: 5 V DC, 1.2 A, 6 W
• Total output power: 18 W
• Connection: screw terminals
• Housing material: plastic
• Colour: grey/black

Tips

Ensure the wall box has enough depth for the power supply and wiring. For best performance, keep the ambient temperature within the specified range.
