Kaiser Elektro UP caja electrónica de mecanismo 1068-05 4x3 domos roscados tornillos de mecanismo

The Kaiser Elektro UP Electronic Device Box 1068-05 is a high-quality flush-mounted electronic device box designed for professional installation in masonry and concrete. This orange plastic box features a depth of 54 mm and an outer diameter of 60 mm, making it ideal for housing electronic components, smart home modules, and relays. It comes with 4x3 screw domes and device screws for secure mounting.

Advantages

This electronic device box offers several benefits: it is halogen-free and flame retardant for enhanced safety, airtight to prevent drafts, and features multiple flexible cable entries for easy wiring. The screw domes ensure a stable and reliable installation.

Suitable for

• Flush-mounted installations in masonry and concrete walls
• Electronic components, smart home modules, relays
• Use with standard 60 mm device boxes

Key specifications

• Installation Type: Flush-mounted (UP)
• Box Type: Electronic Device Box
• Outer Diameter: 60 mm
• Installation Depth: 54 mm
• Material: Plastic
• Halogen-free: Yes
• Number of Device Screws: 3
• Screw Dome Type: With screw domes
• Air-tight: Yes
• Cable Entries: Multiple flexible entries
• Combination Distance: 71 mm
• Suitable for: Masonry, Concrete (Massivbau)
• Application: Electronic components, Smart Home modules, Relays
• Protection Class: IP20
• Flame Retardant: Yes
• Color: Orange

Recommendations

For optimal performance, use this box with compatible flush-mounted accessories and ensure proper installation according to local electrical codes.
