Klauke ST1717 Terminal tubular de cobre estañado 16 mm² M8 100 uds.

The Klauke ST1717 is a high-quality tin-plated copper tubular cable lug designed for reliable and durable electrical connections. Manufactured by Klauke, a trusted brand in professional crimping technology, this cable lug is ideal for stranded copper conductors up to 16 mm² cross-section. With a bolt hole diameter of M8 (8.4 mm), it ensures a secure fit for various applications. Each pack contains 100 pieces, making it suitable for both small repairs and large-scale installations.

Advantages

Tin-plated surface provides excellent corrosion resistance and long-term conductivity. Electrolytic copper (E-Cu) material ensures high electrical performance. Complies with DIN 46235 standard for quality assurance. Inspection hole allows for easy verification of proper conductor insertion. RoHS compliant for environmental safety.

Suitable for

• Electrical installations in industrial and commercial settings
• Power distribution systems
• Control cabinets and switchgear
• Automotive and marine applications
• Renewable energy systems (solar, wind)

Key specifications

• Conductor Cross-Section: 16 mm²
• Bolt Hole Diameter: M8 (8.4 mm)
• Material: Electrolytic Copper (E-Cu)
• Surface Treatment: Tin-plated
• Connection Type: Crimp
• Lug Type: Tubular Cable Lug
• Quantity per Pack: 100 pieces
• Standard Compliance: DIN 46235
• Application: For stranded copper conductors
• Temperature Resistance: Up to 120 °C
• Voltage Rating: Up to 1000 V
• Inspection Hole: Yes
• RoHS Compliant: Yes
• Wall Thickness: Standard
• Manufacturer Series: ST

Recommendations

For optimal performance, use with Klauke crimping tools and dies. Ensure proper conductor stripping and insertion before crimping. Always follow local electrical codes and manufacturer instructions.
