Kyocera PARTS DP UNIT SP (302TB93012)

The Kyocera DP-7110 document processor transforms compatible TASKalfa MFPs into high-volume scanning hubs. Unlike basic ADFs that struggle with mixed originals or duplex jobs, this top-mounted unit delivers a 140-sheet capacity and blazing 160 ipm duplex scanning at 300 dpi, making it the go-to choice for offices that digitise large document sets daily.

Highlights

• Reversing Automatic Document Processor (RADP) with 140-sheet input tray
• Scans up to 160 images per minute (duplex, 300 dpi) in mono or colour
• Handles documents from A6R to A3, including mixed sizes and weights
• Intelligent features: skip blank pages, mixed original detection, ultrasonic multi-feed detection
• Direct top-mount installation on Kyocera TASKalfa 2552ci, 3252ci, 4002i, 5002i, 6002i, 7002i, 8002i and newer 2553ci/3253ci/4003i/5003i/6003i/7003i/8003i series

In daily use

Load up to 140 sheets and let the DP-7110 work through stacks without constant refills. The reversing mechanism scans both sides in a single pass, while the mixed original detector automatically adjusts for different paper sizes. Skip blank page technology eliminates wasted scans, and the ultrasonic sensor prevents double feeds. Whether archiving contracts, scanning invoices, or digitising reports, this processor keeps pace with high-volume workflows.

Full specifications

• Product Type: Document Processor Unit (ADF)
• ADF Type: Reversing Automatic Document Processor (RADP)
• ADF Capacity: 140 sheets (80 g/m²)
• Scanning Speed (Mono Duplex): Up to 160 ipm at 300 dpi
• Scanning Speed (Colour Duplex): Up to 160 ipm at 300 dpi
• Maximum Document Size: A3 (297 x 420 mm)
• Minimum Document Size: A6R (105 x 148 mm)
• Document Weight (Simplex): 35–160 g/m²
• Document Weight (Duplex): 50–160 g/m²
• Key Features: Duplex scanning, mixed original detection, skip blank page, ultrasonic multi-feed detection
• Installation Type: Top-mounted on compatible MFP
• Colour: Black/White
• Compatible Kyocera MFP Series: TASKalfa 2552ci, 3252ci, 4002i, 5002i, 6002i, 2553ci, 3253ci, 4003i, 5003i, 6003i, 7002i, 8002i, 7003i, 8003i

Final note

Engineered for reliability and speed, the DP-7110 is an essential upgrade for any document-intensive environment using Kyocera TASKalfa MFPs.
