LogiLink PHC0103 set de cables de extensión solar, 2 unidades, 5 m, PVC, negro

Solar extension cable set for photovoltaic systems, providing a 5 m reach with durable PVC insulation and IP67-rated connectors. Connect solar panels with confidence using this 2-piece set, rated for 1000 V DC and 30 A, with 4 mm² tinned copper conductors for efficient power transmission.

Advantages

The PVC jacket and connector housing resist UV and harsh weather, ensuring long-term outdoor use. Tinned copper conductors offer excellent corrosion resistance and conductivity, while the IP67 connectors protect against dust and water immersion, maintaining a reliable connection in demanding environments.

Suitable for

• Extending connections between solar panels and inverters
• Outdoor photovoltaic installations exposed to sunlight and moisture
• Systems requiring high current capacity up to 30 A

Key specifications

• Cable length: 5 m
• Connector type: Solar plug (male) to solar socket (female)
• Rated voltage: 1000 V DC
• Rated current: 30 A
• Cable cross-section: 4 mm²
• Conductor material: Tinned copper
• Connector protection class: IP67
• Operating temperature range: -40°C to +90°C
• UV resistant
• Color: Black

Recommendations

For safe and efficient solar installations, pair with compatible MC4 connectors and ensure proper cable management to avoid strain on connections.
