LogiLink Set de Pigtails de Fibra Óptica LC Simplex OS2 2,0 m 12 Pigtails 0,9 mm LSZH Amarillo

The LogiLink Fiber Optic Pigtail Set (FL0LC02) is a professional-grade solution for splicing and terminating single-mode fiber optic cables. This set includes 12 individual pigtails, each 2.0 meters long with a 0.9 mm diameter tight-buffered jacket, terminated with LC/UPC simplex connectors. Designed for OS2 single-mode applications, it ensures low insertion loss and high return loss, making it ideal for high-speed data transmission in telecommunications, data centers, and LAN networks.

Advantages

Pre-terminated with LC/UPC connectors for quick and reliable splicing. The LSZH (Low Smoke Zero Halogen) jacket provides enhanced safety in enclosed spaces. Each pigtail is individually tested to meet strict performance standards, ensuring consistent signal integrity.

Suitable for

• FTTH (Fiber to the Home) installations
• Data center patching and splicing
• Telecommunications network termination
• LAN and WAN infrastructure

Key specifications

• Product Type: Fiber Optic Pigtail Set
• Fiber Optic Mode: Single-mode
• Fiber Optic Class: OS2 (ITU-T G.652.D)
• Connector Type: LC Simplex
• Number of Pigtails: 12
• Pigtail Length: 2.0 m
• Pigtail Diameter: 0.9 mm
• Jacket Type: Tight Buffered
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Jacket Color: Yellow
• Ferrule Material: Zirconia Ceramic
• Insertion Loss (Typical): ≤ 0.2 dB
• Return Loss (Typical): ≥ 50 dB (UPC)
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +85°C
• Standards Compliance: IEC 61754-20, TIA/EIA-604-10, RoHS

Recommendations

For optimal performance, use with compatible OS2 single-mode transceivers and patch panels. Ensure proper cleaning of connectors before mating.
