LogiLink Toma de pared Cat.6A apantallada, 2x RJ45, blanca, montaje empotrado/superficial/con cable, 1 unidad (NK4068)

For structured cabling installers and network technicians who need a reliable, high-performance connection point in offices, schools, or industrial environments, this LogiLink Cat.6A wall outlet delivers two shielded RJ45 ports in a compact white housing. It supports 10 Gigabit Ethernet up to 500 MHz, making it suitable for demanding PoE applications and high-speed data transfer. The modular design with LSA+ IDC terminals allows quick and secure termination of solid or stranded conductors (AWG 22-24) according to TIA/EIA 568A/B. The outlet can be mounted flush, surface, or directly on cables, offering flexibility for various installation scenarios.

Key specifications

• Category: Cat.6A (10GBASE-T up to 500 MHz)
• Ports: 2x RJ45, fully shielded (STP)
• Colour: White (similar to RAL 9003)
• Mounting: Flush-mount, surface-mount, cable-mount
• Termination: LSA+ IDC, TIA/EIA 568A/B
• Compatibility: Cat.6, Cat.5e, Cat.5; PoE, PoE+, 4PPoE
• Material: ABS housing, gold-plated contacts
• Packaging: 1 piece

Why choose it

This outlet is engineered for future-proof networks, providing headroom for 10G speeds and high-power PoE devices. Its shielded design minimizes alien crosstalk and electromagnetic interference, ensuring stable connections in electrically noisy environments. The included backbox (as per sibling listing) simplifies installation, and the modular jack design allows for easy re-termination if needed.

Ideal use cases

• Office workstations requiring dual network drops
• Classrooms and conference rooms with high-density connectivity
• Industrial settings where shielded cabling is mandatory
• Retrofit projects where surface or cable mounting is preferred

Good to know

The outlet is backward compatible with lower categories, so it can be used in existing Cat.5e or Cat.6 installations. It supports all PoE standards up to 4PPoE, making it suitable for powering devices like IP cameras, wireless access points, and VoIP phones. The white colour blends seamlessly with standard wall plates and décor.
