Marco de carcasa Rittal CP 6206.320, gris, compatible con sistema CP, 130 mm de profundidad

Rittal CP 6206.320 is a grey enclosure frame from the Rittal CP system with a 130 mm depth. Designed as a structural element for electrical and electronic housings, this frame supports the installation of mounting panels, modules and door assemblies within control cabinets and instrument enclosures. The compatible CP system profile allows integration with CP accessories and standard panel cutouts, providing a modular basis for industrial and commercial installations.

Advantages

The enclosure frame provides a stable, corrosion-resistant support structure for internal components and panels while maintaining consistent alignment for doors and interfaces. Its standardized CP system dimensions enable straightforward mounting of accessories, simplify assembly and replacement processes, and ensure compatibility with common control cabinet fittings. The neutral grey finish offers broad applicability across different installation environments.

Suitable for

Key specifications

How to use

Mount the frame into the cabinet opening following the CP system alignment and fastening points. Install internal mounting panels and modules onto the frame using the specified CP accessory points and fasteners, ensuring proper grounding and cable entry planning. Fit door assemblies or front panels to the frame, check hinge and seal alignment, and verify clearances for installed components before energizing the system.

Recommendations

Ensure compatibility with other CP system accessories prior to installation and use appropriate fasteners and sealing elements for the intended environmental conditions. For electrical safety and compliance, follow applicable standards for earthing, cable routing and component spacing during assembly.
