MDT SCN-RT1UP.G1 Termostato KNX, blanco puro brillante

The KNX room temperature controller offers precise temperature regulation with an integrated sensor and a clear LCD display. Its four push buttons allow direct setpoint adjustment and mode selection, making it a reliable component for building automation.

Advantages

Flush-mounted design fits standard 55mm switch ranges. The controller supports multiple control modes including 2-point, PI, and switching PI, ensuring compatibility with various heating and cooling systems. Operating modes include Comfort, Standby, Night, and Frost Protection, providing flexible climate management.

Suitable for

• KNX-based smart homes and buildings
• Heating and cooling control in residential or commercial spaces
• Integration with GIRA Standard 55 or Jung A 500 frames

Key specifications

• Display: LCD
• Control elements: 4 push buttons
• Integrated sensor: temperature
• Control modes: 2-point, PI, switching PI
• Operating modes: Comfort, Standby, Night, Frost Protection
• Bus system: KNX
• Power supply: KNX bus voltage
• Current consumption: approx. 10 mA
• Operating temperature: 0 to +45 °C
• Measurement range: 0 to +50 °C
• Humidity range: 5% to 93% (non-condensing)
• Material: plastic

Recommendations

For optimal performance, install in a location away from direct sunlight or drafts. Use with compatible KNX actuators for complete climate control.
