MENNEKES 853 conector push-in, 1 polo, 24 A, 450 V, 0,5-2,5 mm², transparente

Rated for 24 A at 450 V, the MENNEKES 853 is a single-pole push-in wire connector that accepts solid or stranded conductors from 0.5 to 2.5 mm² without tools.

Overview

The MENNEKES 853 is a screwless terminal designed for quick, reliable electrical connections. Its push-in mechanism allows for tool-free insertion of solid conductors or stranded conductors with ferrules, with a wire stripping length of 11 mm. The transparent polyamide housing provides visual confirmation of the connection, while the copper alloy contact ensures low resistance and long-term stability.

What stands out

• Tool-free push-in termination saves installation time.
• Transparent housing allows visual inspection of the wire position.
• Wide operating temperature range from -30°C to +100°C.
• Compact and lightweight, suitable for free wiring in junction boxes or fixtures.

Technical details

• Connection type: Push-in (screwless)
• Number of poles: 1
• Rated voltage: 450 V
• Rated current: 24 A
• Wire cross-section (solid): 0.5 - 2.5 mm²
• Wire cross-section (stranded with ferrule): 0.5 - 2.5 mm²
• Wire stripping length: 11 mm
• Housing material: Polyamide (PA)
• Contact material: Copper alloy
• Colour: Transparent
• Operating temperature range: -30°C to +100°C
• Flammability rating: UL94 V-2
• Approvals: VDE, ENEC
• Mounting type: Free wiring

Our verdict

A dependable push-in connector for solid and ferruled stranded wires up to 2.5 mm², with a transparent body that simplifies inspection.
