METZ CONNECT 142M2X20010 Cable de conexión CAT 6a S/FTP 1 m gris

The METZ CONNECT 142M2X20010 is a high-performance CAT 6a S/FTP patch cable designed for reliable 10 Gigabit Ethernet connections. With a length of 1 meter and a grey LSZH jacket, this cable is ideal for data centers, enterprise networks, and demanding industrial environments where signal integrity and safety are paramount.

Advantages

This cable offers superior shielding with S/FTP construction (pairs in metal foil plus overall braid) to minimize crosstalk and electromagnetic interference. The stranded bare copper conductors (AWG 26/7) provide flexibility while maintaining excellent conductivity. The molded snagless boots protect the RJ45 connectors during installation and removal, ensuring long-term durability.

Suitable for

• 10GBASE-T networks (10 Gigabit Ethernet)
• Data center patching and server connections
• High-speed local area networks (LAN)
• PoE, PoE+, and 4PPoE applications (IEEE 802.3af/at/bt)
• Industrial environments requiring LSZH jacket for fire safety

Key specifications

• Cable Type: Patch Cable, S/FTP (PiMF)
• Category: CAT 6a (Class EA)
• Length: 1 m
• Connectors: RJ45 (8P8C) both ends, gold-plated contacts
• Conductor: Bare copper, AWG 26/7 stranded
• Wiring Standard: TIA/EIA 568B
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Colour: Grey
• Frequency Bandwidth: Up to 500 MHz
• Data Transfer Rate: 10 Gbps
• PoE Support: Yes (PoE, PoE+, 4PPoE)
• Flammability Rating: IEC 60332-1
• Operating Temperature: -20°C to +60°C
• Standards: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2

Recommendations

For optimal performance in high-speed networks, pair this cable with compatible CAT 6a switches and patch panels. The LSZH jacket makes it suitable for use in plenum spaces and areas with strict fire codes.
