METZ CONNECT Caja empotrable IP44 2 puertos para módulo MC gris - Accesorio de red

The METZ CONNECT flush-mount housing IP44 is a robust and reliable solution for installing data network outlets in indoor environments. Designed for use with METZ CONNECT MC modules (Keystone format), this unpopulated housing provides a clean, professional finish for flush-mounted installations. With an IP44 rating, it offers protection against solid objects larger than 1mm and splashing water, making it suitable for areas requiring enhanced protection.

Advantages

This housing ensures a secure and tidy installation of network modules. Its IP44 protection makes it ideal for locations where dust and water splashes are a concern. The flush-mount design integrates seamlessly into walls, providing a sleek appearance. The housing is halogen-free and features UL94 V-0 flame retardancy, enhancing safety in building infrastructure.

Suitable for

• Data network outlets (RJ-45, etc.)
• Voice outlets
• Flush-mounted installations in offices, homes, and commercial spaces
• Indoor network infrastructure requiring IP44 protection

Key specifications

• Product Type: Flush-mount data outlet housing
• Number of Ports: 2
• Module Compatibility: METZ CONNECT MC Modules (Keystone format)
• Ingress Protection (IP) Rating: IP44
• Mounting Type: Flush-mount (Unterputz)
• Colour: Grey (RAL 7035)
• Material: PC/ABS (Polycarbonate/Acrylonitrile Butadiene Styrene)
• Halogen-free: Yes
• Flame Retardancy: UL94 V-0
• Design: Unpopulated (empty)
• Cable Entry: Rear
• Operating Temperature: -5 °C to +50 °C
• Relative Humidity: 10 - 90 % (non-condensing)
• Standards Compliance: DIN EN 50173-1, ISO/IEC 11801
• Installation Depth: Approx. 40 mm

Recommendations

For optimal performance, pair this housing with genuine METZ CONNECT MC modules. Ensure proper cable management and adhere to installation guidelines for flush-mounting. This housing is designed for indoor use only.
