MIBOXER FUT038M LED Controlador Classic Series RGB-W DC12/24V

The MIBOXER FUT038M is a high-performance LED controller from the Classic Series, designed for RGB-W LED strips and lights. It supports both 12V and 24V DC input, delivering reliable control for a wide range of lighting applications. With 2.4GHz wireless technology, it is compatible with MiBoxer/Mi-Light remotes and WiFi gateways, enabling convenient remote control and smart home integration.

Advantages

This controller offers smooth 0-100% dimming and color mixing for RGBW LEDs, with a maximum output power of 120W at 12V or 240W at 24V. Its screw terminal connections ensure secure installation, and the compact ABS housing is suitable for indoor use. The 30m control range provides flexibility in placement.

Suitable for

• RGBW LED strip lighting in living rooms, bedrooms, and commercial spaces
• Smart home lighting systems compatible with MiBoxer/Mi-Light ecosystem
• DIY projects requiring wireless LED control

Key specifications

• Product Type: LED Controller
• LED Type Compatibility: RGBW
• Input Voltage: DC 12V-24V
• Output Current per Channel: 6A
• Max Output Current (Total): 10A
• Max Output Power (12V): 120W
• Max Output Power (24V): 240W
• Wireless Technology: 2.4GHz RF
• Control Method: Wireless Remote / WiFi Gateway
• Number of Channels: 4 (RGBW)
• Connection Type: Screw Terminals
• Operating Temperature: -20°C to 60°C
• Compatibility: MiBoxer/Mi-Light 2.4GHz remotes and WiFi gateways
• Dimming Range: 0-100%
• Housing Material: ABS Plastic
• Protection Rating: IP20 (Indoor Use)
• Control Distance: Up to 30m

Recommendations

For optimal performance, use with compatible MiBoxer/Mi-Light remotes (e.g., FUT092, FUT089, B4, T4) or WiFi gateway (e.g., WL-Box1). Ensure power supply matches voltage and current requirements.
