MIBOXER FUT043+ Controlador LED Classic Series RGB-CCT DC12/24V

The MIBOXER FUT043+ LED Controller from the Classic Series is a versatile RGB-CCT (RGB+Warm White+Cold White) controller designed for use with 12V or 24V LED strips. It supports 2.4GHz RF wireless control, offering reliable operation up to 30 meters. With 5 channels (Red, Green, Blue, Warm White, Cold White) and a maximum output of 720W at 24V, this controller is ideal for creating dynamic lighting effects in residential or commercial spaces.

Advantages

Compatible with MiBoxer/Mi-Light 2.4GHz remotes, wall panels, and WiFi gateway (WL-Box1). Features overload and short circuit protection for safe operation. PWM dimming ensures smooth color mixing and brightness control.

Suitable for

• RGB+CCT LED strip installations
• Smart home lighting systems
• Commercial accent lighting
• DIY lighting projects

Key specifications

• Input Voltage: DC 12V-24V
• Output Current per Channel: 6A
• Total Max Output Current: 30A
• Max Output Power: 360W (12V) / 720W (24V)
• Channels: 5 (R, G, B, WW, CW)
• Control: 2.4GHz RF Wireless
• Control Distance: Up to 30m
• Dimming: PWM
• Operating Temperature: -20°C to 60°C
• Connection: Screw Terminals
• Housing: ABS Plastic
• Static Power Consumption: <1W
• Certifications: CE, RoHS

Recommendations

For best performance, use with compatible MiBoxer/Mi-Light 2.4GHz controllers and ensure proper power supply matching. Suitable for indoor use only.
