MIBOXER SYS Series cable de entrada de alimentación 20cm 18AWG conector de 2 pines a cable desnudo para tiras LED

The MIBOXER SYS Series Power Input Cable is an essential accessory for connecting SYS series LED products to a compatible power supply. Designed for plug-and-play installation on the system side and screw terminal connection on the PSU side, this cable ensures a reliable and secure power link for your LED lighting setup.

Advantages

This cable simplifies the wiring process for SYS series LED controllers and strips, eliminating the need for soldering or custom connectors. The 20cm length provides flexibility in positioning the power supply, while the 18AWG wire gauge supports up to 6A current and 144W power, making it suitable for medium to high-power LED installations. The durable PVC insulation and ABS connector ensure long-lasting performance in indoor environments.

Suitable for

• Connecting MIBOXER SYS series LED controllers to a 24V DC power supply
• Extending power reach between LED strips and PSU
• Replacing damaged or missing power cables in SYS series systems

Key specifications

• Brand: MIBOXER
• Model: S3
• Product Type: Power Input Cable
• Connector Type (System Side): 2-Pin SYS Series Connector
• Connector Type (Power Supply Side): Bare Wire (Red/Black)
• Voltage Rating: DC 24V
• Max Current: 6A
• Max Power: 144W
• Cable Length: 20 cm
• Wire Gauge: 18AWG
• Number of Conductors: 2 (Positive, Negative)
• Cable Material: PVC Insulation, Copper Conductors
• Connector Material: ABS Plastic
• Color: Black (Connector), Red/Black (Wires)
• Application: LED System Power Connection
• Environmental Rating: Indoor Use
• Installation Type: Plug-and-Play (System Side), Screw Terminal (PSU Side)
• Certifications: CE, RoHS

Recommendations

For optimal performance, use this cable with a 24V DC power supply that matches the current and power requirements of your LED system. Ensure the bare wire ends are properly secured in the PSU screw terminals with correct polarity (red = positive, black = negative).
