MICROCONNECT Cable de fibra óptica SC/UPC a SC/UPC OM4 15m - Aqua LSZH dúplex

Engineered for high-speed data centres and enterprise networks, this 15-metre OM4 fibre patch cable delivers exceptional bandwidth and low latency for 100GbE applications. With premium SC/UPC connectors and a durable LSZH jacket, it ensures reliable, high-performance connectivity where it matters most.

Overview

This MICROCONNECT patch cable is a duplex multimode OM4 fibre link, terminated with SC/UPC connectors on both ends. The 50/125µm core and cladding provide optimal performance for high-density cabling environments, supporting data rates from 10GbE up to 100GbE. The aqua-coloured LSZH jacket not only meets strict safety standards but also offers easy identification in crowded racks.

What stands out

• Supports 100GbE data rates, future-proofing your network infrastructure.
• Ultra-low insertion loss (≤0.3 dB) and high return loss (≥30 dB) for reliable signal integrity.
• LSZH (Low Smoke Zero Halogen) jacket ensures safety in confined spaces.
• Precision-polished UPC connectors minimize back reflection.
• Compliant with TIA/EIA-568-C.3 and IEC 60793-2-10 standards.

Technical details

• Connector Type: SC/UPC to SC/UPC
• Fiber Type: OM4 Multimode (50/125µm)
• Cable Length: 15 metres
• Number of Fibers: 2 (Duplex)
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Jacket Colour: Aqua
• Insertion Loss: ≤0.3 dB (typical)
• Return Loss: ≥30 dB (typical)
• Minimum Bend Radius: 7.5 mm
• Operating Temperature: -20°C to +70°C
• Attenuation at 850nm: ≤3.0 dB/km
• Attenuation at 1300nm: ≤1.0 dB/km
• Cable Diameter: 3.0 mm

Our verdict

For network administrators and IT professionals seeking a reliable, high-performance fibre link, this OM4 patch cable delivers outstanding value. Its robust construction and superior optical characteristics make it an excellent choice for demanding data centre environments.
