Microconnect FIB461001 cable InfiniBand/fibra óptica 1 m LC amarillo

Microconnect FIB461001 is a 1 m single mode fibre optic cable with LC–LC connectors and OS2 fibre. With a 9 µm core diameter and yellow jacket, the cable is designed for high-speed data links such as 1G/10G/40G/100G Ethernet and InfiniBand, offering low attenuation for links up to 10 km at 1310 nm and up to 40 km at 1550 nm. The cable uses LSZH materials and meets common industry standards (IEC, EIA/TIA, Telcordia).

Advantages

The LC OS2 single mode patch cord provides low signal loss and consistent performance over long distances, is compact thanks to LC connectors, and has a yellow LSZH jacket for easy identification in racks and cable trays. It supports a range of high-speed network applications while keeping physical footprint and weight minimal.

Suitable for

• Enterprise network backbones
• Telecom rooms and server farms
• Cloud storage networks and data centres
• Connecting 1G/10G/40G/100G Ethernet and InfiniBand links

Key specifications

• Length: 1 m
• Fibre type: OS2 (single mode)
• Core diameter: 9 µm
• Connectors: LC to LC
• Colour: Yellow
• Cable jacket: LSZH
• Standards: IEC, EIA/TIA, Telcordia
• Weight: 0.006 kg

How to use

Inspect connectors for dust or damage before installation. Route the 1 m LC–LC patch cord between compatible LC ports on transceivers, switches or routers, avoiding tight bends and sharp edges. For best performance, ensure connector endfaces are clean and securely latched in the LC adapters.

Recommendations

Use this single mode LC OS2 patch cord for point-to-point fibre links within racks or between adjacent equipment; for longer or routed runs, choose appropriate cable management and observe specified maximum bend radius and handling procedures.
